Material: Optical glass K9 (or customized material).
Dimensions: Customizable length, width, and height.
Angle: Customizable right angle (90 degrees) or other specified angles.
Coating: Optional anti-reflective (AR) coating or other specialized coatings.
Surface Quality: Standard or customized surface quality (e.g., scratch-dig).
Surface Flatness: Standard or customized flatness (e.g., λ/4, λ/10).
Surface Accuracy: Standard or customized accuracy (e.g., λ/4, λ/10).
Clear Aperture: Customizable clear aperture size for optimal light transmission.
Dimensions: Customizable based on project requirement.
Angle: 90 degrees (right angle).
Surface Quality: Typically 40-20 scratch-dig (or as per custom specifications).
Flatness: λ/4 at 632.8 nm (or as per custom requirements).
Coating: Optional anti-reflection coatings available for enhanced performance.
Customization: As the hot series of optical glass components, it can be customized with specific dimensions, angles, coatings, or any other required specifications.
| Technical requirements | Tolerance range |
| size range | 1~400mm |
| diameter tolerance | +0/-0.05mm |
| thickness tolerance | ±0.05mm |
| parallelism tolerance | ±2''~±5'' |
| surface quality | 40-20 |
| surface precision | λ/10 per @633nm |
| bevelling | 0.1-0.5mm |
| material | optical glass or infrared optical material |
| coating film | visible light and infared band |
Enhanced Precision: Customized optical glass K9 right angle prisms offer enhanced precision in various applications. By tailoring the prism’s dimensions, angles, and coatings to specific requirements, manufacturers can achieve higher accuracy and performance in optical systems.
Improved Optical Performance: Customization allows for the selection of high-quality optical glass materials that offer superior transmission properties, low dispersion, and minimal absorption. This results in improved optical performance, including better light transmission, reduced chromatic aberration, and enhanced image quality.
Tailored Design: Customized K9 right angle prisms can be designed to meet specific application needs. Manufacturers can modify the prism’s size, shape, and surface finishes to fit into tight spaces or integrate seamlessly into complex optical setups. This flexibility enables optimal integration and functionality in various systems.
Versatility: Customization enables the adaptation of K9 right angle prisms for a wide range of applications. Whether it’s for laser systems, imaging devices, spectroscopy, or scientific research, manufacturers can customize the prism’s specifications to ensure compatibility and optimal performance in specific environments and applications.
Cost-effectiveness: Customized K9 right angle prisms can offer cost savings in the long run. By tailoring the prism’s design and specifications to meet specific requirements, manufacturers can eliminate unnecessary features or materials, reducing production costs and optimizing the prism’s performance for the intended application.
